LCS3588

The LCS3588 core module is a full-featured core module meticulously designed based on the Rockchip RK3588 chip platform, with dimensions of only 65mm by 50mm. The connection between the core module and the baseboard uses 4 100Pin board-to-board connectors with a 0.4mm pitch, and is secured with 4 M2 screws. It truly brings out all the external pin signals of the RK3588, while also considering high-speed data transmission capabilities, a variety of stacking height options, automation assembly compatibility, vibration resistance and floating functions, a wide operating temperature range, high reliability, compliance with environmental standards, error-proof design, and quality materials and surface treatment, meeting the demands of harsh environments and high-speed communication needs.

LCB3588/J/M

LCB3588 core module is a full-featured core module based on Rexchip Microelectronics RK3588 chip platform, the size of only 75mm * 70mm. the core module and the connection of the backplane using two 0.8mm pitch 140Pin board-to-board connector and four 0.5mm pitch 30Pin FPC connector combination, and through four M2 screws fixed; really all lead out all the external pin signals of the RK3588, while taking into account the reliability, low cost, high flexibility needs. The core module is connected to the chassis by two 0.8mm pitch 140Pin board-to-board connectors and four 0.5mm pitch 30Pin FPC connectors, which are fixed by four M2 screws.

LCB3588S

The LCB3588S core module is a fully functional core module meticulously designed based on the Rockchip RK3588 chip platform, with dimensions of only 75mm by 70mm. The connection between the core module and the baseboard uses two 140-pin board-to-board connectors with a 0.8mm pitch and four 30-pin FPC connectors with a 0.5mm pitch, secured with four M2 screws. This design fully exposes all the external pin signals of the RK3588S, while also meeting the requirements for high reliability, low cost, and high flexibility. In practical applications, the FPC connectors can be added or omitted based on the specific functional requirements. Compared to card-edge connectors or connectors with smaller pitch (such as 0.5mm), it offers higher reliability and yield assurance in harsh industrial environments or in long-term vibration vehicle environments.

LCB3568/J

The LCB3568 is a fully functional core module meticulously designed based on the Rockchip RK3568 series chip platform, with dimensions of only 60mm by 40mm. The connection between the core module and the baseboard is facilitated by four dual-slot 80-pin board-to-board connectors with a 0.5mm pitch, secured with four M2 screws, ensuring stability and reliability, and making it easy to install and maintain.

LKS3588

The LKS3588 is a multifunctional development and evaluation board carefully designed based on the Rockchip RK3588 chip platform, consisting of our company's LCS3588 core module and baseboard. The core module is connected to the baseboard via a B2B connector and secured with four M2 screws, ensuring stability and reliability. The board features a variety of functions, a rich set of interfaces, compact size, and a slim, flat profile, making it suitable for products with limited structural space.

LKD3588

The LKD3588 is a multifunctional development and evaluation board carefully designed based on the Rockchip RK3588 chip platform, consisting of our company's LCB3588 core module and baseboard. The core module is connected to the baseboard with a B2B connector and secured with four M2 screws, ensuring stability and reliability. The board features a variety of functions, rich interfaces, compact size, and a slim and flat design, making it suitable for products with limited structural space.

LKD3588S

The LKD3588S is a multifunctional development and evaluation board meticulously designed based on the Rockchip RK3588 chip platform. It is composed of our company's LCB3588S core module and a baseboard. The core module connects to the baseboard using a B2B connector and is secured with four M2 screws, ensuring stability and reliability. The board is versatile in functionality, rich in interfaces, compact in size, and slim and flat, making it suitable for products with limited structural space.

LKD3568

The LKD3568 is a multifunctional industry application board carefully designed based on the Rockchip RK3568 chip platform. It consists of our company's LCB3568 core module and a baseboard. The core module connects to the baseboard using a B2B connector and is secured with four M2 screws, ensuring stability and reliability. The board offers a variety of functions and rich interfaces, making it widely applicable in numerous scenarios.

LPB3588

The LPB3588 is a smart computing device that is meticulously designed based on the Rockchip RK3588 chip. The body is made of full aluminum material with a fanless design and an innovative internal structure that efficiently conducts heat from the main heat-generating components such as the CPU and PMU to the external aluminum casing, using the entire body casing as a heat dissipation material. This design not only allows the LPB3588 to perform excellently in more demanding working environments but also enables its widespread application in various industrial scenarios.

LPC3588

The LPC3588 is a smart computing device that has been carefully designed around the Rockchip RK3588 chip. Constructed with a full aluminum body, it features a fanless design and an innovative internal structure that effectively channels heat from critical components such as the CPU and PMU to the external aluminum casing, utilizing the entire body casing as a heat sink. This design not only ensures that the LPC3588 can perform exceptionally well in more challenging work environments but also facilitates its broad application across various industrial settings.

LPM3588

The LPM3588 is a smart computing device meticulously crafted based on the Rockchip RK3588 chip. It features a full aluminum body, a fanless design, and an innovative internal structure that allows for efficient heat conduction from key heat-generating components such as the CPU and PMU to the external aluminum casing, effectively using the entire body casing as a heat dissipation material. This design not only enables the LPM3588 to excel in more demanding work environments but also ensures its extensive application in a variety of industrial scenarios.

LPB3568

The LPB3568 smart host is a meticulously designed intelligent host based on the Rockchip RK3568 chip platform. The body is made of full aluminum material with a fanless design. Through an innovative internal structural combination, the key heat-generating components such as the CPU and PMU directly conduct heat to the external aluminum casing, making the entire body casing act as a heat dissipation material. This allows the LPB3568 to withstand harsher working environments and be widely applied in various industrial scenarios.

LPA3588

The LPA3588 smart computing device, crafted with a full aluminum body and a fanless cooling solution, achieves efficient heat dissipation through an innovative internal structure, ensuring stable application across various industrial scenarios. This device offers 3 USB 3.0 HOST ports and 1 full-function Type-C interface, which support the connection of multiple USB cameras. Additionally, it is equipped with 2 mini-PCIe slots for the expansion of 4G/5G modules or NPU computing cards, providing flexibility for a wide range of applications.

LPA3568

The LPA3568 intelligent host is a smart mainframe carefully designed based on the Rockchip RK3568 chip platform; it supports the simultaneous connection of 8 AHD cameras, with each camera capable of supporting a maximum input resolution of 1920*1080 at 30Hz. The AHD cameras use the industry-standard GX12 aviation connectors, which are known for their high reliability and stability. With the simultaneous connection of multiple cameras, it can be utilized for panoramic stitching and as an ADAS (Advanced Driver Assistance System) vehicle intelligent terminal.

LPA3399Pro

The LPA3399Pro smart computing device is developed based on the Rockchip RK3399Pro platform, designed for portable computing hosts that require substantial visual computing capabilities. It features an integrated NPU (Neural Processing Unit) with a computational power of 3.0TOPS and supports a variety of algorithmic models. This product serves as a foundational piece of equipment in AI scenarios, equipped with a rich array of hardware interfaces. Users simply need to port their algorithms to this platform to quickly implement their products.

LPS3399Pro

The LPS3399Pro vision host is a smart host carefully designed based on the Rockchip RK3399Pro chip platform. It features an all-aluminum body with a fanless design and an innovative internal structure that directly conducts heat from key heat-generating components such as the CPU and PMU to the external aluminum casing, effectively using the entire body casing as a heat dissipation material. This design not only allows the LPS3399Pro to withstand more demanding working conditions but also enables its broad application across various industry applications.
